• Rating：35VDC 10mA
• Travel：1.0 mm
• Contact Resistance：50mΩ Max
• Insulation Resistance：100MΩ min(DC 250V)
• Dielectric Strength：250VAC 50/60Hz FOR 1 min
• Operating Force：130±60g/200±80g
• Electric Life：100,000/50,000 cycles
• Operating Temperature Range：-20℃ ~ + 70℃
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Electric Life | Operating Temperature Range | Travel | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R509K-01L(With LED) | 35VDC 10mA | 50mΩ Max | 100MΩ min(DC 250V) | 250VAC 50/60Hz FOR 1 min | 130±60g/200±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 1.0 mm | 暫無 |
| R509K-01 | 35VDC 10mA | 50mΩ Max | 100MΩ min(DC 250V) | 250VAC 50/60Hz FOR 1 min | 130±60g/200±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 1.0 mm | 暫無 |
| R509K-03L(With LED) | 35VDC 10mA | 50mΩ Max | 100MΩ min(DC 250V) | 250VAC 50/60Hz FOR 1 min | 130±60g/200±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 1.0 mm | 暫無 |
| R509K-03 | 35VDC 10mA | 50mΩ Max | 100MΩ min(DC 250V) | 250VAC 50/60Hz FOR 1 min | 130±60g/200±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 1.0 mm | 暫無 |
| R509K-04L(With LED) | 35VDC 10mA | 50mΩ Max | 100MΩ min(DC 250V) | 250VAC 50/60Hz FOR 1 min | 130±60g/200±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 1.0 mm | 暫無 |
| R509K-04 | 35VDC 10mA | 50mΩ Max | 100MΩ min(DC 250V) | 250VAC 50/60Hz FOR 1 min | 130±60g/200±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 1.0 mm | 暫無 |
| R509K-05 | 35VDC 10mA | 50mΩ Max | 100MΩ min(DC 250V) | 250VAC 50/60Hz FOR 1 min | 130±60g/200±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 1.0 mm | 暫無 |
| R509K-06 | 35VDC 10mA | 50mΩ Max | 100MΩ min(DC 250V) | 250VAC 50/60Hz FOR 1 min | 130±60g/200±80g | 100,000/50,000 cycles | -20℃ ~ + 70℃ | 1.0 mm | 暫無 |
