• Rating：12VDC 50mA
• Contact Resistance：100mΩ Max
• Insulation Resistance：250VDC FOR 1 min
• Dielectric Strength：250VAC（50/60Hz） FOR 1 min
• Life Test：100,000 cycles
• Operation Force&Travel：See Specification
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Life Test | Operation Force&Travel | PDF下載 |
|---|---|---|---|---|---|---|---|
| R597-1L | 12VDC 50mA | 100mΩ Max | 250VDC FOR 1 min | 250VAC 50/60Hz FOR 1 min | 100,000 cycles | See Specification | 暫無 |
| R597-1ML | 12VDC 50mA | 100mΩ Max | 250VDC FOR 1 min | 250VAC 50/60Hz FOR 1 min | 100,000 cycles | See Specification | 暫無 |
